Overhead Conveyor Blaster

Overhead Conveyor Blaster – Automatic Continuous Shot‑Blasting System with Multi‑Turbine Coverage for Industrial Surface Treatment

Overhead Conveyor Blaster is an industrial‑grade solution from Botou Junda Machinery Equipment Co., Ltd., designed for continuous automated surface treatment in high‑volume production environments. Integrating heavy‑duty overhead chain with four high‑efficiency blast turbines, the system delivers full 360‑degree coverage at a processing rate of 120‑180 hooks per hour. It features infinitely variable VFD chain speed control ranging from 0.5 to 3 m/min and a robust 50 kg load capacity per hook, achieving Sa 2.5 surface cleanliness standard with stable performance across diverse workpiece geometries. Backed by our 3,000 m² manufacturing plant and 20 years of casting machinery expertise, every unit adopts multi‑layer sealing technology and a centralized abrasive recovery system to lower operational costs.

What Makes Overhead Conveyor Blaster Stand Out

Traditional batch blasting systems create production bottlenecks and inconsistent surface finishes. This Overhead Conveyor Blaster eliminates these pain points via continuous chain‑feed operation that directly interfaces with painting and coating lines.

The four‑turbine layout positions blast units at top, bottom, left and right angles. As workpieces travel and rotate inside the chamber, every surface receives uniform abrasive impact without manual repositioning. This multi‑directional design removes blind spots commonly found in single‑angle blasting equipment.

Variable‑frequency drive technology adjusts chain speed according to rust severity. Heavily corroded components move at 0.5 m/min to extend blasting exposure time, while lightly oxidized parts pass through at 3 m/min to maximize throughput. Such flexibility adapts to changing production requirements without equipment modification.

The industrial‑grade overhead chain supports 50 kg per hook during continuous operation. Reinforced I‑beam structure and dedicated load‑bearing links resist deformation over long production runs, maintaining precise workpiece positioning throughout the shot‑blasting cycle.

Technical Specifications

Core Performance Advantages

Full‑Automatic Production Integration

The overhead chain conveyor runs continuously without batch‑based interruptions. It can be directly connected to loading stations, paint booths and drying ovens to build a seamless workflow. Manual material handling between processes is eliminated, cutting labour costs for high‑volume factories.

Precise Speed Control for Variable Workloads

The infinitely variable frequency‑regulation system matches chain speed to surface condition requirements. Operators adjust conveying speed in real time based on rust thickness to guarantee complete removal while preventing over‑blasting on delicate substrates.

Complete Surface Coverage System

Strategically arranged turbines produce overlapping blasting patterns. As hooks rotate during travel, abrasive streams reach recessed areas, inner cavities and complex geometries. Consistent cleaning grade is maintained across the entire workpiece surface.

Heavy‑Duty Chain Engineering

Specialized industrial chain comes with reinforced links and precision bearings. Its 50 kg capacity accommodates medium‑sized structural parts, castings and assembled components. Regular lubrication ensures smooth operation over years of service life.

Advanced Containment Technology

Multiple flexible curtain layers at chamber inlet and outlet contain abrasive media inside the blasting zone. This sealing design prevents shot spillage into adjacent work areas and reduces media consumption by minimizing losses during continuous operation.

Automated Media Management

An integrated screw conveyor system continuously recycles steel shot from the chamber floor. Automatic recirculation removes frequent manual refilling and stabilizes abrasive flow for blast turbines throughout production shifts.

Flexible Operation Modes

Continuous mode handles standard components at maximum throughput for mass production. Step mode pauses workpieces inside the blasting chamber for extended treatment of heavy‑scaled or geometrically complex parts. Operators switch modes via control panel with no mechanical adjustments required.

Scalable System Design

Modular construction supports chamber length extension, installation of extra turbines and track widening. Manufacturing facilities can upgrade capacity as production demands grow, without replacing core equipment infrastructure.

Industrial Applications

Overhead Conveyor Blaster serves manufacturers requiring consistent surface treatment for a wide range of component types.

Automotive foundries deploy this system for cylinder heads, gearbox housings and suspension parts. The gentle overhead suspension avoids damage to machined surfaces while removing casting sand from internal passages.

Steel‑structure manufacturers prepare weldments, frames and brackets for powder coating or galvanizing. The multi‑angle blasting pattern accesses passages, pipe interiors and welded joints unreachable by manual methods.

Agricultural equipment manufacturers process tractor chassis, implement frames and harvester components. The 50 kg hook capacity handles medium‑size assemblies while delivering the throughput required for seasonal production cycles.

Mining equipment producers clean conveyor components, crusher parts and excavator attachments. Adjustable chain speed copes with heavy mill scale typical on hot‑rolled steel and generates anchor patterns needed for protective coatings.

Frequently Asked Questions

Q: How many hooks can be processed per hour?

A: The standard model achieves 120‑180 hooks per hour with 50 kg per hook, which is the upper limit for small, lightly rusted parts.

Q: Can overhead chain speed be adjusted for heavily rusted workpieces?

A: The chain is equipped with variable‑frequency drive; reduce travelling speed to extend blasting contact time for thorough rust removal.

Q: Can this machine connect to coating production lines?

A: Yes. Transition hanging chains directly link the blasting station with electrophoretic coating, spray painting and drying procedures to cut intermediate‑handling labour.

Q: Will the overhead track deform after long‑term operation?

A: Thickened I‑beam overhead structure plus regular lubrication ensures no obvious deformation within 3‑5 years.

Why Choose Junda Machinery

Our manufacturing philosophy combines proven mechanical design with customisation capability. Every Overhead Conveyor Blaster undergoes performance testing before shipment to verify chain load capacity, turbine balance and sealing integrity.

We deliver complete technical documentation including operation manuals, maintenance schedules and troubleshooting guides. Remote installation support helps your team achieve proper setup and calibration. On‑site commissioning service is available upon request to secure optimal performance from the very first production run.

Standard machines are shipped from available stock, while custom configurations are normally completed within 15 days. Our engineering team replies to technical enquiries within 6‑8 hours to support project timelines with efficient communication.

ISO9001, ISO14001 and ISO45001 certifications validate our quality management system. For export requirements, we assist with CE certification applications and provide technical documents for customs clearance.

Get Your Custom Solution

Ready to boost your surface‑treatment efficiency? Contact our engineering team via junda001@jundablast.com to discuss your specific Overhead Conveyor Blaster requirements, output targets and facility‑integration needs. We will provide technical recommendations tailored for your application.
